Box External Dimensions Width × Height × Depth |
15.75" × 13.78" × 15.94" |
| Material Thickness | 0.83" |
| Net Internal Volume | 1.41 ft3 |
| Tuning Frequency | 40 Hz |
| Port Area | 14.7 inch2 |
| Pipe Inner Diameter | 4.33" |
| Pipe Length | 13.30" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 15.75" × 15.94" | 2 |
| Front / Rear | 15.75" × 12.13" | 2 |
| Left / Right | 14.28" × 12.13" | 2 |
