Subwoofer Box Specifications
Enclosure Name: Gothic GW124
Subwoofer Brand: Power Acoustik
Subwoofer Size: 12 inch
Subwoofer Count: 4
|
Box External Dimensions Width × Height × Depth |
44.25" × 35.75" × 21.48" |
| Material Thickness | 0.75" |
| Net Internal Volume | 10.00 ft3 |
| Tuning Frequency | 30 Hz |
| Port Area | 220 inch2 |
| Port Inlet Width × Height |
6.42" × 34.26" |
| Port Length | 47.73" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 44.25" × 21.48" | 2 |
| Front | 37.08" × 34.26" | 1 |
| Rear | 44.25" × 34.26" | 1 |
| Left | 19.98" × 34.26" | 1 |
| Right | 20.73" × 34.26" | 1 |
| Port | 13.56" × 34.26" | 1 |
| Port | 26.26" × 34.26" | 1 |
