Box External Dimensions Width × Height × Depth |
26.00" × 14.00" × 18.49" |
| Material Thickness | 0.75" |
| Net Internal Volume | 2.60 ft3 |
| Tuning Frequency | 27 Hz |
| Port Area | 21 inch2 |
| Port Inlet Width × Height |
1.68" × 12.50" |
| Port Length | 24.26" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 26.00" × 18.49" | 2 |
| Front | 23.57" × 12.50" | 1 |
| Rear | 26.00" × 12.50" | 1 |
| Left | 17.00" × 12.50" | 1 |
| Right | 17.74" × 12.50" | 1 |
| Port | 15.31" × 12.50" | 1 |
| Port | 5.76" × 12.50" | 1 |
