Box External Dimensions Width × Height × Depth |
29.53" × 15.75" × 18.14" |
| Material Thickness | 0.63" |
| Net Internal Volume | 2.65 ft3 |
| Tuning Frequency | 31.5 Hz |
| Port Area | 38.8 inch2 |
| Port Inlet Width × Height |
2.67" × 14.49" |
| Port Length | 32.11" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 29.53" × 18.14" | 2 |
| Front | 26.22" × 14.49" | 1 |
| Rear | 29.53" × 14.49" | 1 |
| Left | 16.88" × 14.49" | 1 |
| Right | 17.51" × 14.49" | 1 |
| Port | 14.21" × 14.49" | 1 |
| Port | 13.97" × 14.49" | 1 |
