Subwoofer Box Specifications
Enclosure Name: 3 elite 25 kx
Subwoofer Brand: Focal
Subwoofer Size: 10 inch
Subwoofer Count: 3
|
Box External Dimensions Width × Height × Depth |
38.00" × 14.00" × 12.75" |
| Material Thickness | 0.75" |
| Net Internal Volume | 2.50 ft3 |
| Tuning Frequency | 27 Hz |
| Port Area | 14.3 inch2 |
| Port Inlet Width × Height |
1.15" × 12.50" |
| Port Length | 16.57" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 38.00" × 12.75" | 2 |
| Front | 36.11" × 12.50" | 1 |
| Rear | 38.00" × 12.50" | 1 |
| Left | 11.25" × 12.50" | 1 |
| Right | 12.00" × 12.50" | 1 |
| Port | 10.11" × 12.50" | 1 |
| Port | 3.83" × 12.50" | 1 |
