Box External Dimensions Width × Height × Depth |
23.62" × 11.81" × 11.85" |
| Material Thickness | 0.79" |
| Net Internal Volume | 1.06 ft3 |
| Tuning Frequency | 37 Hz |
| Port Area | 15.5 inch2 |
| Port Inlet Width × Height |
1.52" × 10.24" |
| Port Length | 23.98" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 23.62" × 11.85" | 2 |
| Front | 21.32" × 10.24" | 1 |
| Rear | 23.62" × 10.24" | 1 |
| Left | 10.28" × 10.24" | 1 |
| Right | 11.07" × 10.24" | 1 |
| Port | 8.76" × 10.24" | 1 |
| Port | 12.12" × 10.24" | 1 |
