Box External Dimensions Width × Height × Depth |
18.00" × 18.00" × 16.39" |
| Material Thickness | 0.75" |
| Net Internal Volume | 1.75 ft3 |
| Tuning Frequency | 45 Hz |
| Port Area | 24 inch2 |
| Port Inlet Width × Height |
1.45" × 16.50" |
| Port Length | 12.25" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 18.00" × 16.39" | 2 |
| Front / Rear | 18.00" × 16.50" | 2 |
| Left | 14.90" × 16.50" | 1 |
| Right | 12.70" × 16.50" | 1 |
| Port | 12.25" × 16.50" | 1 |
