Box External Dimensions Width × Height × Depth |
31.50" × 17.72" × 25.64" |
| Material Thickness | 1.00" |
| Net Internal Volume | 4.59 ft3 |
| Tuning Frequency | 29 Hz |
| Port Area | 64.2 inch2 |
| Port Inlet Width × Height |
4.08" × 15.72" |
| Port Length | 34.98" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 31.50" × 25.64" | 2 |
| Front | 26.41" × 15.72" | 1 |
| Rear | 31.50" × 15.72" | 1 |
| Left | 23.64" × 15.72" | 1 |
| Right | 24.64" × 15.72" | 1 |
| Port | 19.56" × 15.72" | 1 |
| Port | 9.34" × 15.72" | 1 |
