Box External Dimensions Width × Height × Depth |
30.00" × 14.00" × 15.12" |
| Material Thickness | 0.70" |
| Net Internal Volume | 2.00 ft3 |
| Tuning Frequency | 30 Hz |
| Port Area | 28 inch2 |
| Port Inlet Width × Height |
2.22" × 12.60" |
| Port Length | 35.46" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 30.00" × 15.12" | 2 |
| Front | 27.07" × 12.60" | 1 |
| Rear | 30.00" × 12.60" | 1 |
| Left | 13.72" × 12.60" | 1 |
| Right | 14.42" × 12.60" | 1 |
| Port | 11.49" × 12.60" | 1 |
| Port | 20.34" × 12.60" | 1 |
