Box External Dimensions Width × Height × Depth |
29.00" × 16.00" × 14.89" |
| Material Thickness | 0.75" |
| Net Internal Volume | 2.10 ft3 |
| Tuning Frequency | 31 Hz |
| Port Area | 31 inch2 |
| Port Inlet Width × Height |
2.14" × 14.50" |
| Port Length | 34.55" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 29.00" × 14.89" | 2 |
| Front | 26.11" × 14.50" | 1 |
| Rear | 29.00" × 14.50" | 1 |
| Left | 13.39" × 14.50" | 1 |
| Right | 14.14" × 14.50" | 1 |
| Port | 11.25" × 14.50" | 1 |
| Port | 19.66" × 14.50" | 1 |
