Box External Dimensions Width × Height × Depth |
35.43" × 23.62" × 7.54" |
| Material Thickness | 0.71" |
| Net Internal Volume | 2.30 ft3 |
| Tuning Frequency | 32 Hz |
| Port Area | 23.3 inch2 |
| Port Inlet Width × Height |
1.05" × 22.20" |
| Port Length | 20.75" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 35.43" × 7.54" | 2 |
| Front | 33.68" × 22.20" | 1 |
| Rear | 35.43" × 22.20" | 1 |
| Left | 6.12" × 22.20" | 1 |
| Right | 6.83" × 22.20" | 1 |
| Port | 5.07" × 22.20" | 1 |
| Port | 13.22" × 22.20" | 1 |
