Box External Dimensions Width × Height × Depth |
30.00" × 17.00" × 17.98" |
| Material Thickness | 1.00" |
| Net Internal Volume | 3.18 ft3 |
| Tuning Frequency | 30 Hz |
| Port Area | 25.2 inch2 |
| Port Inlet Width × Height |
1.68" × 15.00" |
| Port Length | 17.60" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 30.00" × 17.98" | 2 |
| Front | 27.32" × 15.00" | 1 |
| Rear | 30.00" × 15.00" | 1 |
| Left | 15.98" × 15.00" | 1 |
| Right | 16.98" × 15.00" | 1 |
| Port | 13.30" × 15.00" | 1 |
