Box External Dimensions Width × Height × Depth |
26.00" × 48.00" × 20.79" |
| Material Thickness | 0.68" |
| Net Internal Volume | 10.00 ft3 |
| Tuning Frequency | 32 Hz |
| Port Area | 136 inch2 |
| Port Inlet Width × Height |
2.92" × 46.64" |
| Port Length | 21.54" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 26.00" × 20.79" | 2 |
| Front / Rear | 26.00" × 46.64" | 2 |
| Left | 19.43" × 46.64" | 1 |
| Right | 15.83" × 46.64" | 1 |
| Port | 21.54" × 46.64" | 1 |
