Box External Dimensions Width × Height × Depth |
31.50" × 13.78" × 18.53" |
| Material Thickness | 0.63" |
| Net Internal Volume | 2.30 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 23.3 inch2 |
| Port Inlet Width × Height |
1.86" × 12.52" |
| Port Length | 16.38" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 31.50" × 18.53" | 2 |
| Front / Rear | 31.50" × 12.52" | 2 |
| Left | 17.27" × 12.52" | 1 |
| Right | 14.78" × 12.52" | 1 |
| Port | 16.38" × 12.52" | 1 |
