Box External Dimensions Width × Height × Depth |
27.56" × 11.81" × 13.38" |
| Material Thickness | 0.71" |
| Net Internal Volume | 1.59 ft3 |
| Tuning Frequency | 32.1 Hz |
| Port Area | 15.5 inch2 |
| Port Inlet Width × Height |
1.49" × 10.39" |
| Port Length | 20.69" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 27.56" × 13.38" | 2 |
| Front | 25.36" × 10.39" | 1 |
| Rear | 27.56" × 10.39" | 1 |
| Left | 11.96" × 10.39" | 1 |
| Right | 12.67" × 10.39" | 1 |
| Port | 10.47" × 10.39" | 1 |
| Port | 7.31" × 10.39" | 1 |
