Box External Dimensions Width × Height × Depth |
23.62" × 15.20" × 18.51" |
| Material Thickness | 0.71" |
| Net Internal Volume | 2.63 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 31 inch2 |
| Port Inlet Width × Height |
2.25" × 13.78" |
| Port Length | 19.11" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 23.62" × 18.51" | 2 |
| Front | 20.67" × 13.78" | 1 |
| Rear | 23.62" × 13.78" | 1 |
| Left | 17.09" × 13.78" | 1 |
| Right | 17.80" × 13.78" | 1 |
| Port | 14.84" × 13.78" | 1 |
| Port | 0.60" × 13.78" | 1 |
