Box External Dimensions Width × Height × Depth |
36.00" × 16.00" × 22.37" |
| Material Thickness | 1.00" |
| Net Internal Volume | 4.00 ft3 |
| Tuning Frequency | 36 Hz |
| Port Area | 80 inch2 |
| Port Inlet Width × Height |
5.72" × 14.00" |
| Port Length | 30.64" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 36.00" × 22.37" | 2 |
| Front | 29.28" × 14.00" | 1 |
| Rear | 36.00" × 14.00" | 1 |
| Left | 20.37" × 14.00" | 1 |
| Right | 21.37" × 14.00" | 1 |
| Port | 14.66" × 14.00" | 1 |
| Port | 8.26" × 14.00" | 1 |
