Box External Dimensions Width × Height × Depth |
44.00" × 23.00" × 28.50" |
| Material Thickness | 0.75" |
| Net Internal Volume | 12.00 ft3 |
| Tuning Frequency | 34 Hz |
| Port Area | 150 inch2 |
| Port Inlet Width × Height |
6.98" × 21.50" |
| Port Length | 14.19" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 44.00" × 28.50" | 2 |
| Front | 36.28" × 21.50" | 1 |
| Rear | 44.00" × 21.50" | 1 |
| Left | 27.00" × 21.50" | 1 |
| Right | 27.75" × 21.50" | 1 |
| Port | 13.44" × 21.50" | 1 |
