Box External Dimensions Width × Height × Depth |
24.50" × 15.00" × 15.02" |
| Material Thickness | 0.66" |
| Net Internal Volume | 1.94 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 30 inch2 |
| Port Inlet Width × Height |
2.19" × 13.68" |
| Port Length | 27.33" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 24.50" × 15.02" | 2 |
| Front | 21.65" × 13.68" | 1 |
| Rear | 24.50" × 13.68" | 1 |
| Left | 13.70" × 13.68" | 1 |
| Right | 14.36" × 13.68" | 1 |
| Port | 11.50" × 13.68" | 1 |
| Port | 12.31" × 13.68" | 1 |
