Box External Dimensions Width × Height × Depth |
33.50" × 16.00" × 20.87" |
| Material Thickness | 0.71" |
| Net Internal Volume | 4.00 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 70 inch2 |
| Port Inlet Width × Height |
4.80" × 14.58" |
| Port Length | 28.26" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 33.50" × 20.87" | 2 |
| Front | 27.99" × 14.58" | 1 |
| Rear | 33.50" × 14.58" | 1 |
| Left | 19.45" × 14.58" | 1 |
| Right | 20.16" × 14.58" | 1 |
| Port | 14.65" × 14.58" | 1 |
| Port | 7.39" × 14.58" | 1 |
