Box External Dimensions Width × Height × Depth |
26.00" × 43.00" × 13.99" |
| Material Thickness | 0.75" |
| Net Internal Volume | 6.00 ft3 |
| Tuning Frequency | 33 Hz |
| Port Area | 83 inch2 |
| Port Inlet Width × Height |
2.00" × 41.50" |
| Port Length | 23.10" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 26.00" × 13.99" | 2 |
| Front | 23.25" × 41.50" | 1 |
| Rear | 26.00" × 41.50" | 1 |
| Left | 12.49" × 41.50" | 1 |
| Right | 13.24" × 41.50" | 1 |
| Port | 10.49" × 41.50" | 1 |
| Port | 9.11" × 41.50" | 1 |
