Box External Dimensions Width × Height × Depth |
31.50" × 14.17" × 23.17" |
| Material Thickness | 0.63" |
| Net Internal Volume | 3.53 ft3 |
| Tuning Frequency | 26 Hz |
| Port Area | 46.5 inch2 |
| Port Inlet Width × Height |
3.60" × 12.91" |
| Port Length | 44.13" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 31.50" × 23.17" | 2 |
| Front | 27.26" × 12.91" | 1 |
| Rear | 31.50" × 12.91" | 1 |
| Left | 21.91" × 12.91" | 1 |
| Right | 22.54" × 12.91" | 1 |
| Port | 18.31" × 12.91" | 1 |
| Port | 20.96" × 12.91" | 1 |
