Subwoofer Box for CT Sounds Meso 12 Inch D1

Ported Box for 12 inch Subwoofer


Box External Dimensions
Width × Height × Depth
20.00" × 14.50" × 18.35"
Material Thickness 0.75"
Net Internal Volume 1.68 ft3
Tuning Frequency 37 Hz
Port Area 27.00 inch2
Port Inlet
Width × Height
2.07" × 13.00"
Port Length 25.26"


Detail Size Quantity
Top / Bottom 20.00" × 18.35" 2
Front 17.18" × 13.00" 1
Rear 20.00" × 13.00" 1
Left 16.85" × 13.00" 1
Right 17.60" × 13.00" 1
Port 14.78" × 13.00" 1
Port 6.91" × 13.00" 1
Ø285mm 20.00" 17.18" 18.35" 16.85" 18.35" 16.85" 14.50" 13.00" Top Top Bottom Bottom Rear Front Left Right Rear Front Left Right subbox.pro
