Box External Dimensions Width × Height × Depth |
35.00" × 14.50" × 17.65" |
| Material Thickness | 0.75" |
| Net Internal Volume | 1.50 ft3 |
| Tuning Frequency | 32 Hz |
| Port Area | 22 inch2 |
| Port Inlet Width × Height |
1.69" × 13.00" |
| Port Length | 32.83" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 35.00" × 17.65" | 2 |
| Front | 32.56" × 13.00" | 1 |
| Rear | 35.00" × 13.00" | 1 |
| Left | 16.15" × 13.00" | 1 |
| Right | 16.90" × 13.00" | 1 |
| Port | 14.46" × 13.00" | 1 |
| Port | 15.18" × 13.00" | 1 |
