Box External Dimensions Width × Height × Depth |
30.00" × 13.78" × 18.83" |
| Material Thickness | 0.75" |
| Net Internal Volume | 2.40 ft3 |
| Tuning Frequency | 34 Hz |
| Port Area | 40 inch2 |
| Port Inlet Width × Height |
3.26" × 12.28" |
| Port Length | 31.09" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 30.00" × 18.83" | 2 |
| Front | 26.00" × 12.28" | 1 |
| Rear | 30.00" × 12.28" | 1 |
| Left | 17.34" × 12.28" | 1 |
| Right | 18.09" × 12.28" | 1 |
| Port | 14.08" × 12.28" | 1 |
| Port | 12.26" × 12.28" | 1 |
