Subwoofer Box Specifications
Enclosure Name: Single Pine box 75lt box
Subwoofer Brand: JBL
Subwoofer Size: 12 inch
Subwoofer Count: 1
|
Box External Dimensions Width × Height × Depth |
38.58" × 13.78" × 16.22" |
| Material Thickness | 1.30" |
| Net Internal Volume | 2.65 ft3 |
| Tuning Frequency | 23.1 Hz |
| Port Area | 17.2 inch2 |
| Port Inlet Width × Height |
1.54" × 11.18" |
| Port Length | 27.65" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 38.58" × 16.22" | 2 |
| Front | 35.75" × 11.18" | 1 |
| Rear | 38.58" × 11.18" | 1 |
| Left | 13.62" × 11.18" | 1 |
| Right | 14.92" × 11.18" | 1 |
| Port | 12.08" × 11.18" | 1 |
| Port | 11.44" × 11.18" | 1 |
