Box External Dimensions Width × Height × Depth |
31.50" × 13.78" × 19.71" |
| Material Thickness | 0.71" |
| Net Internal Volume | 3.53 ft3 |
| Tuning Frequency | 27 Hz |
| Port Area | 31.2 inch2 |
| Pipe Inner Diameter | 6.30" |
| Pipe Length | 26.40" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 31.50" × 19.71" | 2 |
| Front / Rear | 31.50" × 12.36" | 2 |
| Left / Right | 18.30" × 12.36" | 2 |
