Box External Dimensions Width × Height × Depth |
52.00" × 19.00" × 17.71" |
| Material Thickness | 0.74" |
| Net Internal Volume | 2.01 ft3 |
| Tuning Frequency | 36 Hz |
| Port Area | 23.3 inch2 |
| Port Inlet Width × Height |
1.33" × 17.52" |
| Port Length | 18.16" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 52.00" × 17.71" | 2 |
| Front | 49.93" × 17.52" | 1 |
| Rear | 52.00" × 17.52" | 1 |
| Left | 16.23" × 17.52" | 1 |
| Right | 16.97" × 17.52" | 1 |
| Port | 14.90" × 17.52" | 1 |
| Port | 0.45" × 17.52" | 1 |
