Box External Dimensions Width × Height × Depth |
35.43" × 19.69" × 19.76" |
| Material Thickness | 0.75" |
| Net Internal Volume | 4.24 ft3 |
| Tuning Frequency | 31 Hz |
| Port Area | 77.5 inch2 |
| Port Inlet Width × Height |
4.26" × 18.19" |
| Port Length | 40.51" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 35.43" × 19.76" | 2 |
| Front | 30.43" × 18.19" | 1 |
| Rear | 35.43" × 18.19" | 1 |
| Left | 18.26" × 18.19" | 1 |
| Right | 19.01" × 18.19" | 1 |
| Port | 14.00" × 18.19" | 1 |
| Port | 20.75" × 18.19" | 1 |
