Box External Dimensions Width × Height × Depth |
31.50" × 20.47" × 15.20" |
| Material Thickness | 0.83" |
| Net Internal Volume | 2.83 ft3 |
| Tuning Frequency | 32 Hz |
| Port Area | 49.6 inch2 |
| Port Inlet Width × Height |
2.63" × 18.82" |
| Port Length | 37.57" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 31.50" × 15.20" | 2 |
| Front | 28.04" × 18.82" | 1 |
| Rear | 31.50" × 18.82" | 1 |
| Left | 13.55" × 18.82" | 1 |
| Right | 14.37" × 18.82" | 1 |
| Port | 10.91" × 18.82" | 1 |
| Port | 22.37" × 18.82" | 1 |
