Box External Dimensions Width × Height × Depth |
45.00" × 10.50" × 14.91" |
| Material Thickness | 0.68" |
| Net Internal Volume | 2.30 ft3 |
| Tuning Frequency | 33 Hz |
| Port Area | 23.3 inch2 |
| Port Inlet Width × Height |
2.54" × 9.14" |
| Port Length | 19.17" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 45.00" × 14.91" | 2 |
| Front | 41.78" × 9.14" | 1 |
| Rear | 45.00" × 9.14" | 1 |
| Left | 13.55" × 9.14" | 1 |
| Right | 14.23" × 9.14" | 1 |
| Port | 11.01" × 9.14" | 1 |
| Port | 4.25" × 9.14" | 1 |
