Box External Dimensions Width × Height × Depth |
39.37" × 10.24" × 12.30" |
| Material Thickness | 0.71" |
| Net Internal Volume | 1.70 ft3 |
| Tuning Frequency | 34 Hz |
| Port Area | 23.3 inch2 |
| Port Inlet Width × Height |
2.64" × 8.82" |
| Port Length | 26.07" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 39.37" × 12.30" | 2 |
| Front | 36.02" × 8.82" | 1 |
| Rear | 39.37" × 8.82" | 1 |
| Left | 10.89" × 8.82" | 1 |
| Right | 11.59" × 8.82" | 1 |
| Port | 8.25" × 8.82" | 1 |
| Port | 13.76" × 8.82" | 1 |
