Box External Dimensions Width × Height × Depth |
35.43" × 27.56" × 26.19" |
| Material Thickness | 1.42" |
| Net Internal Volume | 7.06 ft3 |
| Tuning Frequency | 37 Hz |
| Port Area | 135.6 inch2 |
| Port Inlet Width × Height |
5.48" × 24.72" |
| Port Length | 23.57" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 35.43" × 26.19" | 2 |
| Front | 28.53" × 24.72" | 1 |
| Rear | 35.43" × 24.72" | 1 |
| Left | 23.35" × 24.72" | 1 |
| Right | 24.77" × 24.72" | 1 |
| Port | 16.45" × 24.72" | 1 |
