Box External Dimensions Width × Height × Depth |
24.00" × 12.00" × 15.92" |
| Material Thickness | 0.75" |
| Net Internal Volume | 1.50 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 19.5 inch2 |
| Port Inlet Width × Height |
1.86" × 10.50" |
| Port Length | 23.17" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 24.00" × 15.92" | 2 |
| Front | 21.39" × 10.50" | 1 |
| Rear | 24.00" × 10.50" | 1 |
| Left | 14.42" × 10.50" | 1 |
| Right | 15.17" × 10.50" | 1 |
| Port | 12.56" × 10.50" | 1 |
| Port | 7.26" × 10.50" | 1 |
