Box External Dimensions Width × Height × Depth |
25.00" × 20.00" × 17.90" |
| Material Thickness | 0.75" |
| Net Internal Volume | 3.00 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 48 inch2 |
| Port Inlet Width × Height |
2.59" × 18.50" |
| Port Length | 26.70" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 25.00" × 17.90" | 2 |
| Front | 21.66" × 18.50" | 1 |
| Rear | 25.00" × 18.50" | 1 |
| Left | 16.41" × 18.50" | 1 |
| Right | 17.15" × 18.50" | 1 |
| Port | 13.81" × 18.50" | 1 |
| Port | 8.80" × 18.50" | 1 |
