Subwoofer Box Powerbass ümit

Ported Box for 15 inch Subwoofer


15 inch subwoofer box Powerbass ümit

Subwoofer Box Specifications

Enclosure Name: ümit

Subwoofer Brand: Powerbass

Subwoofer Size: 15 inch

Subwoofer Count: 1

Box External Dimensions
Width × Height × Depth
27.56" × 17.72" × 12.41"
Material Thickness 0.71"
Net Internal Volume 2.50 ft3
Tuning Frequency 30 Hz
Port Area 17.8 inch2
Port Inlet
Width × Height
1.09" × 16.30"
Port Length 16.18"


Detail Size Quantity
Top / Bottom 27.56" × 12.41" 2
Front 25.76" × 16.30" 1
Rear 27.56" × 16.30" 1
Left 11.00" × 16.30" 1
Right 11.70" × 16.30" 1
Port 9.90" × 16.30" 1
Port 3.77" × 16.30" 1
Ø355.8mm 27.56" 25.76" 12.41" 11.00" 12.41" 11.00" 17.72" 16.30" Top Top Bottom Bottom Rear Front Left Right Rear Front Left Right subbox.pro
