Box External Dimensions Width × Height × Depth |
30.00" × 16.50" × 19.33" |
| Material Thickness | 0.75" |
| Net Internal Volume | 3.25 ft3 |
| Tuning Frequency | 31 Hz |
| Port Area | 45.5 inch2 |
| Port Inlet Width × Height |
3.03" × 15.00" |
| Port Length | 31.02" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 30.00" × 19.33" | 2 |
| Front | 26.22" × 15.00" | 1 |
| Rear | 30.00" × 15.00" | 1 |
| Left | 17.84" × 15.00" | 1 |
| Right | 18.59" × 15.00" | 1 |
| Port | 14.81" × 15.00" | 1 |
| Port | 11.68" × 15.00" | 1 |
