Box External Dimensions Width × Height × Depth |
33.00" × 13.78" × 12.33" |
| Material Thickness | 0.63" |
| Net Internal Volume | 2.30 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 23.3 inch2 |
| Port Inlet Width × Height |
1.86" × 12.52" |
| Port Length | 16.38" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 33.00" × 12.33" | 2 |
| Front / Rear | 33.00" × 12.52" | 2 |
| Left | 11.07" × 12.52" | 1 |
| Right | 8.59" × 12.52" | 1 |
| Port | 16.38" × 12.52" | 1 |
