Box External Dimensions Width × Height × Depth |
40.00" × 13.78" × 25.69" |
| Material Thickness | 0.63" |
| Net Internal Volume | 6.00 ft3 |
| Tuning Frequency | 15 Hz |
| Port Area | 25 inch2 |
| Port Inlet Width × Height |
2.00" × 12.52" |
| Port Length | 43.76" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 40.00" × 25.69" | 2 |
| Front | 37.37" × 12.52" | 1 |
| Rear | 40.00" × 12.52" | 1 |
| Left | 24.43" × 12.52" | 1 |
| Right | 25.06" × 12.52" | 1 |
| Port | 22.43" × 12.52" | 1 |
| Port | 18.08" × 12.52" | 1 |
