Subwoofer Box for Cadence ud104

Ported Box for Dual 10 inch Subwoofers


10 inch subwoofer box Cadence ud104

Subwoofer Box Specifications

Enclosure Name: ud104

Enclosure Creator: anonymous

Subwoofer Brand: Cadence

Subwoofer Size: 10 inch

Subwoofer Quantity: 2

Box External Dimensions
Width × Height × Depth
40.94" × 13.78" × 9.45"
Material Thickness 0.71"
Net Internal Volume 2.00 ft3
Tuning Frequency 33 Hz
Port Area 16.3 inch2
Port Inlet
Width × Height
1.31" × 12.36"
Port Length 15.21"


Detail Size Quantity
Top / Bottom 40.94" × 9.45" 2
Front 38.92" × 12.36" 1
Rear 40.94" × 12.36" 1
Left 8.03" × 12.36" 1
Right 8.74" × 12.36" 1
Port 6.72" × 12.36" 1
Port 5.76" × 12.36" 1
Ø231.1mm Ø231.1mm 40.94" 38.92" 9.45" 8.03" 9.45" 8.03" 13.78" 12.36" Top Top Bottom Bottom Rear Front Left Right Rear Front Left Right subbox.pro
