Box External Dimensions Width × Height × Depth |
33.46" × 15.75" × 12.59" |
| Material Thickness | 0.71" |
| Net Internal Volume | 2.30 ft3 |
| Tuning Frequency | 34 Hz |
| Port Area | 31 inch2 |
| Port Inlet Width × Height |
2.16" × 14.33" |
| Port Length | 24.67" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 33.46" × 12.59" | 2 |
| Front / Rear | 33.46" × 14.33" | 2 |
| Left | 11.17" × 14.33" | 1 |
| Right | 8.30" × 14.33" | 1 |
| Port | 24.67" × 14.33" | 1 |
