Box External Dimensions Width × Height × Depth |
32.50" × 15.00" × 21.64" |
| Material Thickness | 0.75" |
| Net Internal Volume | 4.50 ft3 |
| Tuning Frequency | 32 Hz |
| Port Area | 32 inch2 |
| Port Inlet Width × Height |
2.37" × 13.50" |
| Port Length | 11.81" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 32.50" × 21.64" | 2 |
| Front / Rear | 32.50" × 13.50" | 2 |
| Left | 20.14" × 13.50" | 1 |
| Right | 17.02" × 13.50" | 1 |
| Port | 11.81" × 13.50" | 1 |
