Box External Dimensions Width × Height × Depth |
35.83" × 17.32" × 23.66" |
| Material Thickness | 0.71" |
| Net Internal Volume | 5.47 ft3 |
| Tuning Frequency | 31 Hz |
| Port Area | 76.0 inch2 |
| Pipe Inner Diameter | 9.84" |
| Pipe Length | 29.28" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 35.83" × 23.66" | 2 |
| Front / Rear | 35.83" × 15.91" | 2 |
| Left / Right | 22.24" × 15.91" | 2 |
