Box External Dimensions Width × Height × Depth |
34.00" × 32.00" × 15.10" |
| Material Thickness | 0.75" |
| Net Internal Volume | 6.00 ft3 |
| Tuning Frequency | 28 Hz |
| Port Area | 65 inch2 |
| Port Inlet Width × Height |
2.13" × 30.50" |
| Port Length | 27.38" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 34.00" × 15.10" | 2 |
| Front / Rear | 34.00" × 30.50" | 2 |
| Left | 13.60" × 30.50" | 1 |
| Right | 10.72" × 30.50" | 1 |
| Port | 27.38" × 30.50" | 1 |
