Box External Dimensions Width × Height × Depth |
35.83" × 16.54" × 21.35" |
| Material Thickness | 0.87" |
| Net Internal Volume | 4.00 ft3 |
| Tuning Frequency | 30 Hz |
| Port Area | 60 inch2 |
| Port Inlet Width × Height |
4.06" × 14.80" |
| Port Length | 35.42" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 35.83" × 21.35" | 2 |
| Front | 30.91" × 14.80" | 1 |
| Rear | 35.83" × 14.80" | 1 |
| Left | 19.61" × 14.80" | 1 |
| Right | 20.48" × 14.80" | 1 |
| Port | 15.56" × 14.80" | 1 |
| Port | 14.07" × 14.80" | 1 |
