Box External Dimensions Width × Height × Depth |
31.50" × 19.69" × 23.62" |
| Material Thickness | 0.94" |
| Net Internal Volume | 6.40 ft3 |
| Tuning Frequency | 34 Hz |
| Port Area | 44.4 inch2 |
| Pipe Inner Diameter | 7.52" |
| Pipe Length | 8.79" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 31.50" × 23.62" | 2 |
| Front / Rear | 31.50" × 17.80" | 2 |
| Left / Right | 21.73" × 17.80" | 2 |
