Box External Dimensions Width × Height × Depth |
18.90" × 13.78" × 11.22" |
| Material Thickness | 0.59" |
| Net Internal Volume | 1.24 ft3 |
| Tuning Frequency | 49 Hz |
| Port Area | 13.2 inch2 |
| Pipe Inner Diameter | 4.09" |
| Pipe Length | 7.93" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 18.90" × 11.22" | 2 |
| Front / Rear | 18.90" × 12.60" | 2 |
| Left / Right | 10.04" × 12.60" | 2 |
