Box External Dimensions Width × Height × Depth |
28.00" × 16.00" × 26.97" |
| Material Thickness | 0.75" |
| Net Internal Volume | 4.17 ft3 |
| Tuning Frequency | 30.38 Hz |
| Port Area | 61.5 inch2 |
| Port Inlet Width × Height |
4.24" × 14.50" |
| Port Length | 33.46" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 28.00" × 26.97" | 2 |
| Front | 23.01" × 14.50" | 1 |
| Rear | 28.00" × 14.50" | 1 |
| Left | 25.48" × 14.50" | 1 |
| Right | 26.22" × 14.50" | 1 |
| Port | 21.24" × 14.50" | 1 |
| Port | 6.49" × 14.50" | 1 |
