Box External Dimensions Width × Height × Depth |
40.00" × 20.00" × 26.30" |
| Material Thickness | 0.63" |
| Net Internal Volume | 6.50 ft3 |
| Tuning Frequency | 25 Hz |
| Port Area | 100 inch2 |
| Port Inlet Width × Height |
5.33" × 18.74" |
| Port Length | 54.07" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 40.00" × 26.30" | 2 |
| Front | 34.04" × 18.74" | 1 |
| Rear | 40.00" × 18.74" | 1 |
| Left | 25.04" × 18.74" | 1 |
| Right | 25.67" × 18.74" | 1 |
| Port | 19.70" × 18.74" | 1 |
| Port | 27.78" × 18.74" | 1 |
