Box External Dimensions Width × Height × Depth |
37.40" × 13.39" × 18.32" |
| Material Thickness | 0.75" |
| Net Internal Volume | 3.53 ft3 |
| Tuning Frequency | 36 Hz |
| Port Area | 31 inch2 |
| Port Inlet Width × Height |
2.61" × 11.89" |
| Port Length | 11.45" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 37.40" × 18.32" | 2 |
| Front | 34.05" × 11.89" | 1 |
| Rear | 37.40" × 11.89" | 1 |
| Left | 16.82" × 11.89" | 1 |
| Right | 17.57" × 11.89" | 1 |
| Port | 10.70" × 11.89" | 1 |
